ENGINE
Engine type Liquid-cooled;4-stroke;4- valves;DOHC;Forward-inclined parallel 4-cylinder
Displacement 599cc
Bore x stroke 67.0 mm x 42.5 mm
Compression ratio 13.1 : 1
Maximum power 140+ HP
Lubrication system Wet sump
Clutch Type Wet;Multiple Disc
Ignition system TCI
Starter system Electric
Transmission system Constant Mesh;6-speed
Final transmission Chain
Carburetor Electronic Fuel Injection
CHASSIS
Frame Diamond
Caster Angle 24o
Trail 97mm
Front suspension system. Telescopic forks, Ø43 mm
Rear suspension system. Swingarm;(link suspension)
Front travel 120 mm
Rear Travel 120 mm
Front brake Hydraulic dual disc, Ø320 mm
Rear brake Hydraulic single disc, Ø220 mm
Front tyre Pirelli Diablo Supercorsa SC1/SC2 120/70-17
Rear tyre Pirelli Diablo Supercorsa 190/60-17
DIMENSIONS
Overall length 2,040 mm
Overall width 695 mm
Overall height 1,150 mm
Seat height 850 mm
Wheel base 1,375 mm
Minimum ground clearance 130 mm
Wet weight (including full oil and fuel tank) 165 kg
Fuel tank capacity 17 litres
Oil tank capacity 3.4 litres
